SKU: FKSL208KO
Description





Features



DLX+ Material


SMART PERFORMANCE CONSTRUCTION


Particularly good aging resistance, high tear resistance, additional ripstop threads, and enormous stiffness at only 33g / m² make the TX-Light fabric perfect for the upper and lower sails of our foil kites. Inside, the TX-Light Hardfinish fabric enables increased use of cross ports. The leading edge consists of 44g / m² DLX + fabric which better protects against abrasion and sharp-edged objects. Every fabric is optimized for its use, from UV-resistant surfaces and air-impermeable coatings to absorbent properties to improve airflow when wet.








Rigid Foil Technologie


CAMBER TRIM SYSTEM


Bridle levels of the kite are controlled by the mixer, a pulley system which modulates the angle of attack and the profile camber. The mixer features the two-ring camber trim system. Moving the rings changes the relationship between the B or C level relative to the A level. The profile of the foil kite can be trimmed to be either flat or curved.










Double Cordwise Ballooning


4 LEVEL RAM AIR TECHNOLOGY


The 4-Level Ram Air Technology (A, B, C, Z) distributes the forces over the entire profile depth of the foil kite and perfectly meets the requirements of a freeride product. Controlling the 4 levels via the mixer improves turning and supports relaunching. The foil kite changes its angle of attack as well as the profile camber without any loss of stability.








Automatisches Lentzsystem


HIGH PRESSURE AIR INTAKE


The air intakes are integrated into the leading edge and ensure the optimal dynamic pressure in our foil kites. After the foil kite is filled with air, the walls of the air intake are automatically pressed together. The self-deflating is prevented, and the kite holds its wing shape.










Triple Depower


REFLEX PROFILE


The reflex profile keeps the foil kite stable at a low angle of attack and at full acceleration. The counter-arching pushes the trailing edge down and prevents a front stall. The reflex profile is essential for controlling and depowering a foil kite.








Verstärkte Konstruktion


AUTOMATIC DRAINAGE SYSTEM


The Automatic Drainage System hides in the internal construction of our closed-cell foil kites. Dirt, water and small objects that got inside the kite slide automatically from the middle section to the wingtips. They exit the kite through two big holes at the trailing edge of the wingtips.










Verstärkte Konstruktion


BRIDLE CHECK TOOL


The bridle check tool makes it easier to compare the bridle line lengths. At each level (A, B, C, Z), on each wing side of the foil kite, black markings make comparing front and back main line lengths easy (see line plan). To restore the flight characteristics, length differences between B and C levels relative to A level must be annulled by moving the rings on the mixer. To maintain performance and stability, we recommend regularly checking using the bridle check tool, if the product is used intensively.








Double Cordwise Ballooning


PROFILE MOMENTUM ADJUSTER


The PMAs are knot ladders that are sewn onto the profile in inside the foil kite. They sit on the upper and lower sail between the A and B levels. By shortening the knot ladders, the profile camber can be adjusted, which gives the foil kite more performance or stability. If a change is made, it should be made symmetrically. We recommend the help of a FLYSURFER sales partner to ensure correct settings of the Profile Momentum Adjuster.
